约翰迪尔零件查询300B - BACKHOE, LOADER LOWER SEAT SUPPORT AND LINKS (WITH 9250A BACKHOE) (SERIAL NO. -308459) [02B12]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
831 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT29242
|
[1] |
Support
|
|
| 2. |
T30475
|
[6] |
Bushing
|
|
| 3. |
AT29264
|
[1] |
Link
|
|
| 3. |
AT29261
|
[1] |
Link
|
|
| 4. |
24H1211
|
[8] |
Washer
|
|
| 5. |
K40014
|
[4] |
Lock Nut
|
|
| 6. |
19H2644
|
[4] |
Cap Screw
|
|
| 7. |
T30483
|
[2] |
Spring
|
|
| 8. |
E13291
|
[2] |
Eyebolt
|
|
| 9. |
14H732
|
[2] |
Nut
|
|
| 10. |
AT29259
|
[1] |
Link
|
|
| 10. |
AT29257
|
[1] |
Link
|
|
| 11. |
T30476
|
[2] |
Bushing
|
|
| 12. |
19H2898
|
[4] |
Cap Screw
|
|
| 13. |
12H301
|
[4] |
Lock Washer
|
|
| 14. |
T51794
|
[1] |
Bracket
|
|
| 14. |
T51795
|
[1] |
Bracket
|
|
| 15. |
19H3205
|
[2] |
Cap Screw
|
|
| 16. |
24M7044
|
[2] |
Washer
|
|
| 17. |
14H813
|
[2] |
Nut
|
|
| 18. |
AT50152
|
[1] |
Bracket
|
|
