| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT29242 | [1] | Support | |
| 2. | T30475 | [6] | Bushing | |
| 3. | AT29264 | [1] | Link | UPPER, L.H. (SUB FOR AT29263, ALSO ORDER (2) T30475) |
| 3. | AT29261 | [1] | Link | UPPER, R.H. (SUB AT29262 AND (2) T30475) |
| 4. | 24H1211 | [8] | Washer | 9/16" X 1-3/8" X 0.105" |
| 5. | K40014 | [4] | Lock Nut | (SUB FOR BP12214, THIS APPLICATION) |
| 6. | 19H2644 | [4] | Cap Screw | 1/2" X 2-1/2" |
| 7. | T30483 | [2] | Spring | |
| 8. | E18270 | [2] | Eyebolt | |
| 9. | 14H732 | [2] | Nut | 3/8" |
| 10. | AT29259 | [1] | Link | LOWER, L.H. (SUB AT29260, T30475 AND T30476) |
| 10. | AT29257 | [1] | Link | LOWER, R.H. (SUB AT29258, T30475 AND T30476) |
| 11. | T30476 | [2] | Bushing |
