约翰迪尔零件查询300B - BACKHOE, LOADER BACKHOE BUCKET CYLINDER (9250-A BACKHOE) [02H07]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 857 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD7806	[1]	Lubrication Fitting	90°, 1/4"
2.	U40150	[2]	Bushing
3.	AU40099	[1]	Hydraulic Cylinder Barrel
4.	19H1813	[1]	Cap Screw	5/16" X 5/8"
5.	12H303	[1]	Lock Washer	5/16"
6.	24M7207	[1]	Washer	8.400 X 24 X 2 MM
7.	AU40106	[1]	Tube
8.	AH16917	[1]	Adapter Fitting
9.	R26375	[1]	O-Ring
10.	P45231	[1]	Lock Nut
11.	T40416	[1]	Wear Ring	(B)
12.	U17299	[1]	Piston
13.	T38194	[1]	Packing	(B) (SUB FOR R72826)
14.	R495R	[1]	O-Ring	(B)
15.	U17300	[1]	Piston
16.	U14128	[1]	Snap Ring
17.	R76802	[1]	Seal	(B) (SUB FOR T36998)
18.	U41823	[1]	Wear Ring	(B)
19.	U41958	[1]	Guide	(ALSO ORDER U41823)
20.	R86192	[1]	O-Ring	(B) (SUB FOR U12331)
21.	R78823	[1]	Back-Up Ring	(B) (SUB FOR R35684, THIS APPLICATION)
22.	U10136	[1]	Snap Ring
23.	U16406	[1]	Seal	(B)
24.	U10139	[1]	Nut
25.	U10666	[2]	Bushing
26.	AU40101	[1]	Hydraulic Cylinder Rod
27.	JD7797	[1]	Lubrication Fitting	STRAIGHT, 1/4"
...	........	[1]	Hydraulic Cylinder	( AU40107 NO LONGER AVAILABLE) (SUB R35684, U14128, U41958, AU40099, AU40101, JD7797, JD7806, P45231, U10136, U10139, U17299, U17300 AND RE18751) (LESS RETURN TUBE)
...	RE18751	[1]	Hydraulic Cylinder Kit	(SUB FOR AT36829, AR96511 AND AR105405)
