约翰迪尔零件查询302A - BACKHOE, LOADER ENGINE OIL PUMP [01B25]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
679 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R74552
|
[2] |
Screw
|
|
| 2. |
R57059
|
[2] |
Cap Screw
|
|
| 3. |
12H304
|
[2] |
Lock Washer
|
|
| 4. |
R53382
|
[1] |
Cover
|
|
| 5. |
34H280
|
[1] |
Spring Pin
|
|
| 6. |
AR62978
|
[1] |
Pinion
|
|
| 7. |
T20298
|
[1] |
Gear
|
|
| 8. |
14H826
|
[1] |
Nut
|
|
| 9. |
T20091
|
[1] |
Dowel Pin
|
|
| 10. |
AR62979
|
[1] |
Housing
|
|
| 11. |
R54614
|
[1] |
Gear
|
|
| 12. |
R74354
|
[1] |
O-Ring
|
|
| 13. |
R61871
|
[1] |
O-Ring
|
|
| 14. |
RE36425
|
[1] |
Oil Pump Intake
|
|
| 15. |
T20050
|
[1] |
Oil Tube
|
|
| 16. |
12H304
|
[2] |
Lock Washer
|
|
| 16. |
R74553
|
[2] |
Washer
|
|
| 17. |
AR67074
|
[1] |
Oil Pump
|
|
| ... |
AR67670
|
[1] |
Kit
|
|
