约翰迪尔零件查询302A - BACKHOE, LOADER TRANSMISSION LUBRICATING OIL LINES [01F11]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
655 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AR66588
|
[1] |
Oil Cup
|
|
| 1. |
AR87416
|
[1] |
Oil Cup
|
|
| 2. |
R26552
|
[1] |
Ball
|
|
| 3. |
R39090
|
[1] |
Needle Roller
|
|
| 4. |
19H2676
|
[1] |
Cap Screw
|
|
| 4. |
21H1322
|
[1] |
Screw
|
|
| 5. |
24H1307
|
[AR] |
Washer
|
|
| 6. |
A3917R
|
[2] |
O-Ring
|
|
| 7. |
H246R
|
[2] |
Strap
|
|
| 8. |
T22984
|
[1] |
Cap Screw
|
|
| 9. |
R1888R
|
[1] |
Strap
|
|
| 10. |
19H2633
|
[1] |
Cap Screw
|
|
| 11. |
14H732
|
[1] |
Nut
|
|
| 12. |
T22974
|
[1] |
Clamp
|
|
| 13. |
AT29752
|
[1] |
Oil Line
|
|
| 14. |
T22852
|
[1] |
Adapter Fitting
|
|
| 15. |
AR65012
|
[1] |
Oil Line
|
|
