约翰迪尔零件查询302A - BACKHOE, LOADER TRANSMISSION TOP COVER AND SHIFT LEVER [01F12]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
549 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T27559
|
[2] |
Boot
|
|
| 1. |
L31055
|
[2] |
Boot
|
|
| 2. |
L4035T
|
[2] |
Snap Ring
|
|
| 3. |
L4027T
|
[2] |
Bushing
|
|
| 4. |
T19935
|
[1] |
Clamp
|
|
| 5. |
T22728
|
[7] |
Screw
|
|
| 5. |
T22728
|
[5] |
Screw
|
|
| 5. |
19H3181
|
[7] |
Cap Screw
|
|
| 6. |
R60458
|
[2] |
Knob
|
|
| 7A. |
T22809
|
[1] |
Gearshift Lever
|
|
| 7B. |
R53817
|
[2] |
Gearshift Lever
|
|
| 7C. |
L34349
|
[2] |
Gearshift Lever
|
|
| 8. |
T36042
|
[1] |
Gasket
|
|
| 9. |
AT23579
|
[1] |
Cover
|
|
| 9. |
AT23907
|
[1] |
Cover
|
|
| 10. |
R32507
|
[4] |
Snap Ring
|
|
| 11A. |
R53815
|
[2] |
Ball Stud
|
|
| 11B. |
CE14048
|
[2] |
Ball
|
|
| 12. |
L31311
|
[2] |
O-Ring
|
|
| 13. |
34H251
|
[2] |
Spring Pin
|
|
| 14. |
AL32791
|
[2] |
Gearshift Lever
|
|
| 15. |
R29936
|
[2] |
O-Ring
|
|
