| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | L35845 | [1] | Hose | (WITH REVERSER) (SUB FOR T24760, THIS APPLICATION) |
| 2. | AR21839 | [4] | Clamp | |
| 3. | AT22268 | [1] | Oil Line | (WITH REVERSER) |
| 4. | R1662R | [2] | Washer | |
| 5. | AT22145 | [1] | Oil Line | (WITHOUT REVERSER) |
| 6. | T35692 | [1] | Hydraulic Hose | (WITHOUT REVERSER) |
| 7. | T19324 | [2] | Clamp | |
| 8. | T23073 | [1] | Tube | |
| 9. | R44302 | [1] | Tie Band | |
| 10. | R44302 | [1] | Tie Band | |
| 11. | H77698 | [1] | Tie Band | (SUB FOR T44946) |
