约翰迪尔零件查询310 - BACKHOE, LOADER CYLINDER BLOCK (SERIAL NO. 169358- ) [01A22]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
316 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT13740
|
[1] |
Drain Valve
|
|
| 1. |
T29388
|
[1] |
Union Fitting
|
|
| 2. |
15H690
|
[AR] |
Pipe Plug
|
|
| 2. |
T37027
|
[AR] |
Fitting
|
|
| 2. |
15H562
|
[AR] |
Pipe Plug
|
|
| 3. |
R48685
|
[2] |
Dowel Pin
|
|
| 4. |
15H275
|
[AR] |
Pipe Plug
|
|
| 4. |
T29388
|
[AR] |
Union Fitting
|
|
| 5. |
R39741
|
[1] |
Drain Plug
|
|
| 6. |
R122226
|
[2] |
Stud
|
|
| 6. |
T25701
|
[1] |
Stud
|
|
| 7. |
12H304
|
[3] |
Lock Washer
|
|
| 8. |
14H1076
|
[3] |
Nut
|
|
| 9. |
T18891
|
[2] |
Plug
|
|
| 10. |
R26493
|
[1] |
Bushing
|
|
| 11. |
R26650
|
[2] |
Dowel Pin
|
|
| 12. |
15H666
|
[1] |
Pipe Plug
|
|
| 13. |
R48685
|
[2] |
Dowel Pin
|
|
| 14. |
R54802
|
[3] |
Orifice
|
|
| 14. |
22H932
|
[3] |
Set Screw
|
|
| 15. |
R79089
|
[1] |
Cap
|
|
| 16. |
R65215
|
[3] |
Bearing Cap
|
|
| 17. |
T20168
|
[8] |
Washer
|
|
| 18. |
T23474
|
[8] |
Cap Screw
|
|
| 19. |
15H558
|
[4] |
Pipe Plug
|
|
| 20. |
R73139
|
[1] |
Flow Control Hyd. Valve
|
|
| 21. |
R46625
|
[1] |
Spring
|
|
| 22. |
R75892
|
[1] |
O-Ring
|
|
| 23. |
T23435
|
[1] |
Threaded Nipple
|
|
| 24. |
U13639
|
[1] |
O-Ring
|
|
| 25. |
RE19841
|
[1] |
Cylinder Block
|
|
| ... |
RE19842
|
[1] |
Short Block Assembly
|
|
| ... |
........
|
[1] |
Short Block Assembly
|
|
