约翰迪尔零件查询310 - BACKHOE, LOADER FRONT AXLE, SPINDLE AND KNUCKLE ASSEMBLY (SERIAL NO. -237997) [01H09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 747 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1768	[2]	Cap Screw	3/4" X 2"
2.	12H236	[2]	Lock Washer	3/4"
3.	F3607R	[2]	Washer
4.	T21519	[1]	Lever	R.H.
4.	T21520	[1]	Lever	L.H.
5.	T15285	[AR]	Shim	.69 MM (.027")
6.	T15288	[2]	Washer
7.	T34546	[4]	Bushing
8.	T162396	[2]	Lubrication Fitting	(SUB FOR JD7798) 1/8" STRAIGHT
9.	AT33638	[1]	Front Axle
10.	JD7799	[2]	Lubrication Fitting	1/8" 90°
11.	T23170	[1]	Bushing
12.	T23118	[2]	Bushing
13.	........	[1]	Crank	( AT19797 NO LONGER AVAILABLE)
13.	AT32476	[1]	Crank
14.	11M7030	[1]	Cotter Pin	5 X 40 MM
15.	14H534	[1]	Nut	3/4", (SUB FOR 14H902)
16.	T25922	[2]	Washer	(USE IF AVAILABLE)
16.	T151797	[2]	Washer	(SUB FOR T25922 OR T134960)
17.	T25921	[AR]	Shim	.38 MM (.015")
18.	T21669	[1]	Bushing
19.	T25840	[1]	Cap Screw
20.	T23229	[2]	Washer
21.	T23228	[AR]	Shim	.25 MM (.010")
22.	F534R	[1]	Snap Ring
23.	JD8412	[2]	Thrust Bearing
24.	T31749	[2]	Washer
25.	T34548	[2]	Washer
26.	AT33636	[2]	Knuckle
