约翰迪尔零件查询310 - BACKHOE, LOADER GRILLE HOUSING AND HOOD [01H21]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 449 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H1895	[8]	Cap Screw	1/2" X 3/4"
2.	24H1625	[8]	Washer	17/32" X 1" X 0.120"
3.	T33610	[1]	Plate
4.	AT30726	[1]	Housing
5.	T31647	[1]	Pad
6.	T25291	[2]	Reinforcement
7.	12H304	[4]	Lock Washer	3/8"
8.	19H1648	[2]	Cap Screw	3/8" X 3/4"
9.	AR72950	[2]	Grille	(SUB FOR AT35236) (SUB FOR AT19880, THIS APPLICATION)
10.	R26858	[2]	Spring
11.	T31651	[1]	Pad
12.	T31650	[2]	Pad
13.	AT30731	[1]	Hood	(SUB AT37776) (WHEN EQUIPPED WITH CANOPY, ALSO ORDER T38965 MUFFLER EXTENSION, AR45917 CLAMP WITH SCREW AND AR56783 MUFFLER EXHAUST COVER) (WHEN NOT EQUIPPED WITH CANOPY, ALSO ORDER AR45917 CLAMP WITH SCREW, AR56783 MUFFLER EXHAUST COVER AND T38966 M
13.	AT37776	[1]	Hood
14.	19H2284	[2]	Cap Screw	3/8" X 7/8"
15.	24M7101	[2]	Washer	11 X 34 X 3 MM
16.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
17.	T16464	[2]	Lock Nut	(SUB FOR BP12232)
18.	19H2473	[2]	Cap Screw	1/2" X 1-3/4"
19.	24H1111	[2]	Washer	17/32" X 1-1/16" X 0.090"
20.	24H1341	[2]	Washer	17/32" X 15/16" X 0.060"
21.	12H236	[2]	Lock Washer	3/4"
22.	19H2431	[2]	Cap Screw	3/4" X 2-1/4", (SUB FOR 19H1782)
