Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Plug	( T33805 NO LONGER AVAILABLE)
2.	37H24	[AR]	Screw	1/4" X 3/4", (3 USED WITH INSTRUMENT PANEL COVER, 5 USED WITHOUT INSTRUMENT PANEL COVER) (SUB FOR T23876, THIS APPLICATION)
3.	AT34536	[1]	Instrument Panel	(SUB AT38591)
3.	AT56983	[1]	Instrument Panel	(SUB FOR AT38591) (ALSO ORDER T16738)
4.	T33634	[3]	Clip
5.	14H812	[6]	Nut	3/8"
6.	12H304	[6]	Lock Washer	3/8"
7.	T33635	[1]	Cover
8.	12H302	[6]	Lock Washer	1/4"
9.	19H1919	[6]	Cap Screw	1/4" X 5/8"
10.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
11.	19H2284	[4]	Cap Screw	3/8" X 7/8"
12.	T33631	[1]	Retainer
13.	19H2021	[2]	Cap Screw	3/8" X 5/8"
14.	........	[1]	Foam Pad	( T31659 - NO LONGER AVAILABLE)
15.	AR53934	[1]	Cylinder	(SUB FOR AT30732)
15.	AT53934	[1]	Cowl
16.	T31657	[1]	Bumper
17.	T33632	[1]	Retainer
18.	T33617	[1]	Grommet
18.	T48195	[1]	Grommet
19.	T16738	[1]	Plug
20.	M2291T	[1]	Plug
21.	T51209	[1]	Isolator
22.	T16738	[1]	Plug	(WITHOUT PARKING BRAKE INDICATOR LIGHT) (USE WITH AT56983 DASH)
