约翰迪尔零件查询310 - BACKHOE, LOADER ENGINE OVERHAUL GASKET SET (GASOLINE) [02C13]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 695 次

Pos.	Part No	Qty	Parts name	Comments
1.	R131794	[1]	Gasket	(SUB FOR R90648)
2.	T20154	[1]	Gasket
3.	T20328	[1]	Gasket
4.	T20112	[1]	Gasket
5.	T20304	[1]	Washer
6.	T13213	[1]	Washer
7.	R56463	[1]	O-Ring	(SUB FOR R495R, THIS APPLICATION)
8.	R74354	[1]	O-Ring	(SUB FOR R27166, THIS APPLICATION)
9.	R87627	[3]	O-Ring	(SUB FOR R27976, THIS APPLICATION)
10.	AR102261	[1]	Gasket	(SUB FOR T20111) (ALSO ORDER (6) AR103811 CAP SCREWS WITH WASHERS)
11.	T20206	[1]	Gasket
12.	R80241	[1]	Gasket	(USE IF AVAILABLE) (SUB FOR R59447)
12.	R97356	[1]	Engine Cylinder Head Gasket	(SUB FOR R80241)
13.	R70483	[1]	Gasket	(SUB FOR R49516, THIS APPLICATION)
14.	T20232	[1]	Washer
15.	R48768	[3]	Washer
16.	R49514	[1]	Gasket
17.	T10079	[1]	Gasket
18.	R520618	[1]	Gasket	(SUB FOR R97350, R27285)
19.	T20208	[1]	Gasket
20.	T20212	[1]	Gasket
21.	T20215	[1]	Gasket
22.	T20336	[1]	Gasket
23.	T20273	[1]	Gasket
24.	T20243	[1]	Gasket
...	RE501582	[1]	Gasket Kit	(SUB FOR RE40429) (ALSO ORDER (3) AR71618 CYLINDER LINER PACKING KITS AND (6) AR103811 CAP SCREWS WITH WASHERS)
