约翰迪尔零件查询310 - BACKHOE, LOADER BACKHOE SWING FRAME [02E08]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 908 次

Pos.	Part No	Qty	Parts name	Comments
1.	A3581R	[1]	Spring Locking Pin	(SUB FOR 34H321)
2.	T68041	[1]	Pin Fastener	(SUB FOR U41722)
3.	08H4308	[2]	Cap Screw	3/4" X 8"
4.	U43442	[4]	Washer
5.	U43435	[2]	Tapered Sleeve
6.	T35016	[2]	Pin Fastener
7.	U41086	[2]	Bushing	(A)
8.	JD7797	[8]	Lubrication Fitting	(A) 1/4" STRAIGHT
9.	19H3544	[1]	Cap Screw	1/2" X 4-1/2"
10.	U16051	[1]	Pin
11.	BP12214	[1]	Lock Nut	(SUB FOR U12622)
12.	U16070	[2]	Bushing	(A)
13.	AT64768	[1]	Frame	CONSISTS OF PARTS IDENTIFIED BY (A) (SUB FOR AT32806)
14.	U10618	[2]	Bushing	(F) (1.51" I.D. X 1.99" O.D. X 1.59" LENGTH)
14.	T126936	[2]	Bushing	(A) (F) (SUB FOR T47070)
15.	JD7788	[2]	Lubrication Fitting	1/4" 45°
16.	T67205	[2]	Thrust Washer	(SUB FOR U41077)
17.	T55322	[2]	Tapered Sleeve	(SUB FOR T34188)
18.	U11649	[4]	Washer	(E)
18.	U11649	[1]	Washer	USE WITH T37598 PIN
19.	T33688	[4]	Bushing	(A)
20A.	T33690	[1]	Pin Fastener	(E) (SUB T37598, (2) U11649 AND (2) 11H221, THIS APPLICATION)
20A.	T37598	[2]	Pin	(E) (SUB T37598, (2) U11649 AND (2) 11H221, THIS APPLICATION)
20B.	T59453	[2]	Groove Pin	(E) (SUB T37598, (2) U11649 AND (2) 11H221, THIS APPLICATION)
20C.	T37598	[1]	Pin
21.	11M7085	[4]	Cotter Pin	(E) 6.300 X 63 MM
21.	11H221	[4]	Cotter Pin	(E) 3/8" X 2-1/2"
21.	11H221	[1]	Cotter Pin	USE WITH T37598 PIN
22.	T25879	[2]	Nut
23.	T59452	[4]	Snap Ring	(E) USE WITH T59453 PIN
