Pos.	Part No	Qty	Parts name	Comments
1.	AT32993	[1]	Backhoe Boom	(SUB AT64858, AT64860, AT64861, T68031, T39918 AND (2) AT64862)
1.	AT64858	[1]	Backhoe Boom	(SUB FOR AT37152) (ALSO ORDER AT64860, AT64861, T68031, T39918 AND AT64862)
1.	U41535	[1]	Lock	(WELD ON BOOM LOCK)
2.	T33933	[2]	Bushing
3.	JD7759	[2]	Lubrication Fitting	(A) 1/8", STRAIGHT
3.	JD7759	[1]	Lubrication Fitting	(B) 1/8", STRAIGHT
4A.	T33948	[1]	Pin
4B.	T44275	[1]	Pin Fastener
5.	T33945	[2]	Washer
6.	12H304	[4]	Lock Washer	3/8"
7.	JD7759	[3]	Lubrication Fitting	1/8" STRAIGHT
8A.	19H2676	[1]	Cap Screw	3/8" X 1"
8B.	19H3169	[4]	Cap Screw	5/8" X 4-1/4"
9.	19H1781	[3]	Cap Screw	1/2" X 3-1/2"
10.	AT32995	[1]	Pin Fastener	(SUB T37135)
11.	BP12214	[4]	Lock Nut	(SUB FOR U12622)
12.	19H1868	[1]	Cap Screw	1/2" X 3-3/4"
13.	U15822	[1]	Pin	(A)
13.	T39918	[1]	Pin	(B)
14.	AT150728	[1]	Pin Fastener	(SUB FOR T44022) (ALSO ORDER 19H3118 AND 14H1076) (SUB FOR U16970 AND T43740, THIS APPLICATION)
15.	T125914	[2]	Pin Fastener	(SUB FOR T34529)
16.	U11649	[AR]	Washer
17.	T37135	[1]	Pin	(A)
17.	T68031	[1]	Pin Fastener	(B)
18.	JD7797	[2]	Lubrication Fitting	1/4" STRAIGHT
19.	AT32994	[1]	Pivot	(A)
20.	T33949	[1]	Pivot	(SUB T35902)
20.	T35902	[1]	Pivot
21.	U14555	[1]	Lock Nut
