约翰迪尔零件查询310A - BACKHOE, LOADER CLUTCH DISCONNECT AND FLYWHEEL [01H01]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 978 次

Pos.	Part No	Qty	Parts name	Comments
1.	JD9449	[1]	Ball Bearing
2.	RE33891	[1]	Clutch Disk	(SUB FOR AL24059)
3.	AT17464	[1]	Thrust Bearing
4.	19H3483	[8]	Cap Screw	3/8" X 1-1/8"
5.	12H304	[8]	Lock Washer	3/8"
6.	AR69708	[1]	Seal
7.	T22178	[1]	Washer
8.	T22177	[1]	Support
9A.	T22505	[1]	Fork
9B.	T63651	[1]	Fork
10.	T22567	[2]	Pin Fastener
11A.	AT20055	[1]	Housing	CARRIER FOR THROW OUT BEARING, WITH PINS
11B.	AT60365	[1]	Roller Carriage
12.	L372T	[6]	Cap Screw
13.	12H303	[6]	Lock Washer	5/16"
14.	R27320	[1]	Bushing
15.	T24948	[1]	Spring
16.	34H253	[1]	Spring Pin	1/8" X 1-3/8"
17A.	AT27717	[1]	Shaft	CLUTCH FORK
17B.	AT60373	[1]	Shaft	CLUTCH FORK
18.	........	[3]	Pin Fastener	( T11700 NO LONGER AVAILABLE)
19.	........	[3]	Lever	( T11701 AMD T63652 NO LONGER AVAILABLE)
19.	........	[3]	Lever	( T63652 NO LONGER AVAILABLE)
20.	T13267	[3]	Clip
21.	14H882	[3]	Nut	5/16"
22.	........	[3]	Washer	( T13269 NO LONGER AVAILABLE)
23.	H61022	[3]	Cap Screw
24.	........	[3]	Spring	( T24956 NO LONGER AVAILABLE)
25.	........	[1]	Bracket	( H33689 NO LONGER AVAILABLE)
26.	........	[1]	Clutch Plate	( T24955 NO LONGER AVAILABLE)
27.	AR63785	[1]	Plate	(SUB FOR AT22064) (SUB AT60368)
27.	AT60368	[1]	Clutch Plate
28A.	19H2552	[2]	Cap Screw	3/8" X 1-1/8"
28B.	H78097	[4]	Screw	(SUB FOR R49482)
