| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T33534 | [1] | Strap | |
| 2. | 12H304 | [8] | Lock Washer | 3/8" |
| 3. | 19H1648 | [1] | Cap Screw | 3/8" X 3/4" |
| 4. | 19H1726 | [1] | Cap Screw | 3/8" X 2-1/4" |
| 5. | 19H2732 | [1] | Cap Screw | 3/8" X 2-3/4" |
| 6. | 19H3483 | [4] | Cap Screw | 3/8" X 1-1/8" |
| 7. | 19H3385 | [1] | Cap Screw | 1/2" X 1-1/8" |
| 8. | T21448 | [1] | Pin Fastener | |
| 9. | T36042 | [1] | Gasket | |
| 10. | AT39738 | [1] | Cover | (MARKED T40986) |
| 11. | 24H1451 | [1] | Washer | 1-1/32" X 1-3/4" X 0.060" |
| 12. | A602R | [1] | Snap Ring | |
| 13. | 28H860 | [1] | Washer | 3/8" X 3/8" |
| 14. | 19H2552 | [1] | Cap Screw | 3/8" X 1-1/8" |
