约翰迪尔零件查询310A - BACKHOE, LOADER BRAKE VALVE AND OIL LINES [01H17]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 431 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT32335	[3]	Elbow Fitting	90°
2.	R26287	[1]	O-Ring
2.	R26287	[3]	O-Ring
3.	24H1304	[1]	Washer	13/32" X 23/32" X 0.120"
4.	........	[1]	Oil Line	(SUB AT41227)
5.	AR35223	[1]	Elbow Fitting	45°
6.	AT41227	[1]	Kit	L.H.
7.	T30367	[1]	Clamp
8.	19H1648	[2]	Cap Screw	3/8" X 3/4"
9.	R27528	[2]	Clamp
10.	12H304	[2]	Lock Washer	3/8"
11.	T21815	[2]	Retainer
12.	U12547	[2]	O-Ring	(SUB FOR U12547, THIS APPLICATION)
13.	T21813	[2]	Seat
14.	T21814	[2]	Compression Spring
15.	400R	[2]	Ball
16.	........	[2]	Piston	(A) R73933 NO LONGER AVAILABLE, (SUB FOR T22100, THIS APPLICATION) (SUB AT184434)
17.	T21817	[2]	Spring
18.	R36636	[1]	Fitting Plug	(SUB FOR T21806, THIS APPLICATION)
19.	R29936	[1]	O-Ring
20.	15H560	[1]	Pipe Plug	1/16", HEX. CTSK.
21.	AR53493	[1]	Housing	BRAKE VALVE, (MARKED R49664)
22.	19H1936	[1]	Cap Screw	3/8" X 3/4"
23.	R27528	[1]	Clamp
24.	AT41224	[1]	Line	R.H.
25.	T38500	[1]	Angle
26.	12H304	[1]	Lock Washer	3/8"
27.	14H812	[1]	Nut	3/8"
