约翰迪尔零件查询310A - BACKHOE, LOADER HYDRAULIC PUMP FRONT AND REAR PRESSURE OIL LINES [02E22]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询310A - BACKHOE, LOADER HYDRAULIC PUMP FRONT AND REAR PRESSURE OIL LINES [02E22]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 519 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H3239	[1]	Cap Screw	3/8" X 1-1/4"
2.	12H304	[1]	Lock Washer	3/8"
3.	R46414	[1]	Clamp	(SUB FOR AH78125, THIS APPLICATION)
4.	R26906	[1]	O-Ring
5.	R26375	[1]	O-Ring
6A.	AR32665	[1]	Tee Fitting
6B.	AT32332	[1]	Elbow Fitting
7.	AT38634	[1]	Hydraulic Hose - Fabricate	3/4" X 305 MM (12") X 3/4"
7.	AT40598	[1]	Hydraulic Hose - Fabricate	3/4" X 787 MM (31") X 3/4"
8.	AT85136	[1]	Oil Line	(SUB FOR AT33912)
9.	AT33922	[1]	Elbow Fitting	90°
10.	T34889	[1]	Tee Fitting
11A.	AT85137	[1]	Oil Line	(SUB FOR AT33920)
11A.	AT85137	[1]	Oil Line	(SUB FOR AT33920)
11B.	AT85228	[1]	Oil Line	(SUB FOR AT74223)
12.	19H118	[1]	Cap Screw	5/16" X 1"
13.	12H303	[1]	Lock Washer	5/16"
14.	R43475	[2]	Clamp
15.	T16172	[1]	Spacer
16.	14H785	[1]	Nut	5/16"
17.	T34887	[1]	Adapter Fitting
17.	T34887	[1]	Adapter Fitting
17.	T75264	[1]	Fitting
18.	AM31412	[1]	Elbow Fitting
19.	R26448	[1]	O-Ring
20.	T41904	[1]	Clamp
21.	12H294	[1]	Lock Washer	5/8"
22.	19H1916	[1]	Cap Screw	5/8" X 1"
