约翰迪尔零件查询310A - BACKHOE, LOADER HYDRAULIC PUMP RETURN AND DRAIN OIL LINES [02E23]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 271 次

Pos.	Part No	Qty	Parts name	Comments
1.	R39832	[1]	Adapter Fitting
1.	R27346	[1]	Fitting
2.	AT25345	[1]	Line	(SUB AT63378, R36742, R26287, U45768 AND R27346, THIS APPLICATION)
2.	AT63378	[1]	Line
3.	R44302	[8]	Tie Band
4.	AT33919	[1]	Oil Line
5.	AR21839	[2]	Clamp
6.	........	[2]	Hydraulic Hose	25 MM X 76 MM (1" X 3") (MAKE FROM U11186) (SUB FOR T35691 AND T37798)
7.	T36048	[1]	Bracket
8.	12H303	[1]	Lock Washer	5/16"
9.	14H785	[1]	Nut	5/16"
10.	19H1914	[1]	Cap Screw	1/4" X 1"
11.	T34888	[1]	Clamp
12.	T36200	[1]	Clamp
13.	24H1287	[1]	Washer	9/32" X 5/8" X 0.065"
14.	14H786	[1]	Nut	1/4"
15.	AT33921	[1]	Oil Line
16.	19H1849	[1]	Cap Screw	5/16" X 1-1/4"
17.	AT33923	[1]	Adapter Fitting
18.	R1662R	[1]	Washer
19.	R43696	[1]	Washer	(SUB FOR A4231R)
20.	19H2676	[1]	Cap Screw	3/8" X 1"
21.	AT33917	[1]	Elbow Fitting	90°
22.	AT33918	[1]	Oil Line
23.	AR21839	[2]	Clamp	(SUB FOR H2742B, THIS APPLICATION)
24.	AT33916	[1]	Elbow Fitting	90°
25.	U12547	[1]	O-Ring	(SUB FOR F3171R)
