| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7865 | [4] | Screw | M8 X 16 |
| 2. | T77835 | [1] | Self-Locking Screw | (SUB FOR T77834, THIS APPLICATION) |
| 3. | 24H1821 | [1] | Washer | 9/32" X 47/64" X 1/16" |
| 4. | 28H1611 | [1] | Washer | 0.269" X 0.405" X 5/16", (USE WITH AT100589) |
| 5A. | AT135537 | [1] | Cover | (SUB FOR AT100589 AND AT114449, 28H1611) |
| 5B. | AT143468 | [1] | Cover | |
| 6. | AT101909 | [1] | Boot | |
| 7. | T77832 | [4] | Self-Locking Screw | |
| 8. | 24H1136 | [4] | Washer | 11/32" X 11/16" X 0.065", (LOADER VALVE COVER TO FENDER CAPSCREWS) |
| 9. | AT143471 | [1] | Mounting Parts |
