Pos.	Part No	Qty	Parts name	Comments
1.	AT106614	[1]	Cover	(SUB FOR AT100266)
1.	AT106615	[1]	Cover	(WITH EXTENDIBLE DIPPERSTICK) (SUB FOR AT101372)
1.	AT134933	[1]	Cover	USE WITH THREE-LEVER CONTROLS (NOT ILLUSTRATED)
1.	99M7014	[1]	Plug	USE WITHOUT EXTENDIBLE DIPPERSTICK (NOT ILLUSTRATED)
2.	T77835	[12]	Self-Locking Screw	USE WITH CAB
2.	24M7100	[8]	Washer	6.600 X 22 X 2 MM, (BACKHOE VALVE COVER TO BACKHOE CONTROL BOOT SCREWS) (NOT ILLUSTRATED)
2.	T15005	[12]	Plug	(SUB FOR (12) H113924) USED WITH ROPS
3.	M84972	[16]	Nut	4 USED WITHOUT CAB
4.	T124621	[13]	Screw
5.	24M7100	[4]	Washer	6.600 X 22 X 2 MM
6.	AT143028	[2]	Boot	(SUB FOR AT139784) (SUB FOR AT100267, THIS APPLICATION)
6.	AT101913	[1]	Boot	USE WITH THREE-LEVER CONTROLS (NOT ILLUSTRATED)
6.	T105899	[1]	Boot	USE WITH FOUR-LEVER CONTROLS (NOT ILLUSTRATED)
7.	AT100268	[1]	Boot
8.	T101199	[2]	Strip	USE WITH FOUR-LEVER CONTROLS
9.	AT142296	[1]	Plate	(WITH EXTENDIBLE DIPPERSTICK)
10.	T100992	[1]	Label	(WITH EXTENDIBLE DIPPERSTICK)
11.	T127904	[1]	Label	(WITH EXTENDIBLE DIPPERSTICK)
12.	T106070	[1]	Label	(WITH EXTENDIBLE DIPPERSTICK)
