约翰迪尔零件查询315CH - BACKHOE, LOADER TRANSMISSION CASE (WITH FOUR-WHEEL DRIVE) (SERIAL NO. 761935- ) [01C20]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 345 次

Pos.	Part No	Qty	Parts name	Comments
1.	R26448	[1]	O-Ring
2.	15H562	[1]	Pipe Plug	1"
3.	14H971	[1]	Nut	1/2"
4.	T18891	[1]	Plug
5.	T21937	[1]	Plug
6.	15H584	[1]	Pipe Plug	1/2"
7.	R48685	[4]	Dowel Pin
8.	U17409	[1]	O-Ring
9.	T78662	[1]	Drain Plug
10.	T126833	[1]	Threaded Nipple
11.	........	[1]	Pin	( R62129 - USE IF AVAILABLE)
11.	R64350	[1]	Needle Roller	(SUB FOR R62129)
12.	T113166	[2]	Plug
13.	T100628	[1]	Trough
14.	19H1648	[1]	Cap Screw	3/8" X 3/4"
15.	24M1606	[1]	Washer	11 X 20 X 2 MM
16.	AT166585	[1]	Transmission	(MARKED T151754) (SUB FOR AT135685) (MARKED T127166) (ALSO ORDER (4) R48685, T155333, T155426, T155750, T157600, 11M7087, 11M7015, 24M7338 AND (2) 11M7059)
17.	AT68978	[1]	Elbow Fitting	(R.H. LUBE PORT)
18.	R44742	[1]	Dowel Pin
19.	R32101	[2]	Stud
20.	T118848	[1]	Seal
21.	22H993	[1]	Set Screw	1/2" X 1-1/2"
22.	19H2993	[4]	Cap Screw
23.	14H1040	[2]	Nut
24.	T113402	[1]	Cover
25.	R26906	[2]	O-Ring
26.	T58477	[2]	Fitting
27.	RE57836	[2]	Pipe Plug	(SUB FOR 15H624)
