约翰迪尔零件查询315CH - BACKHOE, LOADER POWER TRAIN MOUNTING PARTS (SERIAL NO. 761950- ) [01C21]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
542 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
14M7328
|
[4] |
Lock Nut
|
|
| 2. |
AT113838
|
[1] |
Bracket
|
|
| 2. |
AT113837
|
[1] |
Bracket
|
|
| 3. |
24H1852
|
[8] |
Washer
|
|
| 4. |
AT100048
|
[4] |
Rubber Mount
|
|
| 4. |
AT47712
|
[4] |
Isolator
|
|
| 5. |
19M8020
|
[4] |
Cap Screw
|
|
| 6. |
19H2431
|
[2] |
Cap Screw
|
|
| 7. |
19H2719
|
[2] |
Cap Screw
|
|
| 8. |
19H3205
|
[4] |
Cap Screw
|
|
| 9. |
24M7241
|
[4] |
Washer
|
|
| 10. |
T113322
|
[1] |
Bracket
|
|
| 11. |
T113102
|
[2] |
Strap
|
|
| 12. |
T20217
|
[2] |
Washer
|
|
| 13. |
14H1047
|
[2] |
Nut
|
|
| 14. |
N231749
|
[2] |
Washer
|
|
| 15. |
14H1054
|
[2] |
Nut
|
|
| 16. |
T113101
|
[1] |
Bracket
|
|
