Pos.	Part No	Qty	Parts name	Comments
1.	19M7658	[4]	Cap Screw	M10 X 50
2.	T113220	[1]	Shield	L.H.
3.	AT100417	[2]	Channel
4.	14M7167	[6]	Lock Nut	M10
5.	AT113893	[1]	Hood
6.	19M7867	[2]	Screw	M8 X 25
7.	U42544	[1]	Clamp
8.	AT100393	[1]	Rod
9.	T26072	[1]	Spring
10.	T100165	[1]	Shield	R.H.
11.	AT74878	[2]	Lock	(INCLUDES T42713 NUT)
11.	AT145929	[2]	Key	(SUB FOR (2) AR51481)
12.	AT44188	[8]	Rivet
13.	AT74879	[2]	Latch
14.	24H1219	[4]	Washer	7/16" X 1" X 0.083"
15.	19M7358	[2]	Cap Screw	M10 X 40
16.	14M7303	[2]	Flange Nut	M6
17.	T68133	[1]	Plate
18.	19M7560	[2]	Cap Screw	M6 X 16
18.	24M7088	[2]	Washer	6.600 X 12 X 1.600 MM
19.	H110232	[2]	Washer
20.	T113711	[1]	Isolator
21.	........	[1]	Isolator	( T113708 NO LONGER AVAILABLE)
22.	........	[1]	Isolator	( T113709 NO LONGER AVAILABLE)
23.	T113710	[1]	Isolator
24.	........	[1]	Isolator	( T113707 NO LONGER AVAILABLE)
25.	........	[1]	Isolator	( T113706 NO LONGER AVAILABLE)
26.	24M7239	[2]	Washer	10.700 X 21 X 2.500 MM
27.	T122032	[8]	Barrier
28.	T122031	[2]	Barrier	(USE IF AVAILABLE)
28.	T135732	[2]	Isolator	(SUB FOR T122031)
