| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT74685 | [1] | Hinge | |
| 2. | 24H1136 | [4] | Washer | 11/32" X 11/16" X 0.065" |
| 3. | 19M7865 | [4] | Screw | M8 X 16 |
| 4. | T77833 | [4] | Self-Locking Screw | (SUB FOR T76064) |
| 5A. | R42941 | [AR] | Cap Screw | 1/4" X 0.620" |
| 5B. | E45229 | [AR] | Lock Nut | 1/4", (SUB K40001) |
| 5B. | K40001 | [AR] | Lock Nut | 1/4" |
| 6. | 24H1288 | [2] | Washer | 9/32" X 1" X 1/16" |
| 7. | T19935 | [AR] | Clamp | |
| 8. | AT75686 | [1] | Cover |
