| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7835 | [2] | Screw | M10 X 35 |
| 2. | H110232 | [2] | Washer | |
| 3. | T113699 | [2] | Rod | |
| 4. | ........ | [AR] | Sealant | (MAKE FROM T70307 BULK MATERIAL, CUT TO LENGTH) |
| 5. | T113572 | [1] | Angle | RIGHT |
| 5. | T113573 | [1] | Angle | LEFT (NOT PICTURED) |
| 6. | 14M7167 | [2] | Lock Nut | |
| 7. | AT114330 | [2] | Bracket | |
| 8. | 14M7299 | [2] | Flange Nut | M12 |
| 9. | 19M7789 | [2] | Screw | M12 X 30 |
