| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7867 | [6] | Screw | M8 X 25 |
| 2. | 24H1685 | [10] | Washer | 11/32" X 47/64" X 0.083" |
| 3. | AT113960 | [1] | Fender | |
| 4. | 14M7166 | [4] | Lock Nut | M8 |
| 5. | R64058 | [1] | Grommet | |
| 6. | AT113963 | [1] | Support | |
| 7. | 19M7866 | [2] | Screw | M8 X 20 |
| 8. | 14M7298 | [2] | Flange Nut | M8 |
| 9. | 12H331 | [2] | Lock Washer | 3/8" |
