约翰迪尔零件查询401C - BACKHOE, LOADER RADIATOR ASSEMBLY [01C17]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 559 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT28810	[1]	Radiator	(UNIT WITH OIL COOLER)
1.	AT48171	[1]	Radiator	(SUB FOR AT28583) (UNIT WITHOUT OIL COOLER)
2.	AT20848	[1]	Oil Cooler	(SUB AT169229)
2.	AT169229	[1]	Oil Cooler	(SUB FOR AR69398 AND AT77459 OR AT165535)
3.	T22375	[1]	Pad
4.	14H785	[5]	Nut	5/16"
5.	T22381	[2]	Washer
6.	AT54940	[1]	Shroud	(SUB FOR AR55591)
7.	R61460	[1]	Rod	(SUB FOR T22495)
8.	T23533	[1]	Hose	(DIESEL) UPPER WATER
8.	R38481	[1]	Hose	(DIESEL) (SUB FOR R38312)
8.	T22496	[1]	Hose	(GASOLINE)
9.	T22500	[1]	Hose	LOWER WATER
10.	AT27585	[1]	Cap
11.	12H303	[5]	Lock Washer	5/16"
12.	37H79	[4]	Screw	1/4" X 5/8"
13.	AT13740	[1]	Drain Valve
14.	R62372	[2]	Spring	(SUB FOR R34352)
15.	19H2458	[2]	Cap Screw	3/8" X 3"
16.	19H2664	[1]	Cap Screw	5/16" X 3/4"
17.	24H1122	[1]	Washer	3/8" X 7/8" X 0.083"
18.	24H1685	[4]	Washer	11/32" X 47/64" X 0.083"
19.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
20.	T11234	[2]	Lock Nut
21.	AR21999	[4]	Hose Clamp	(SUB FOR AR21840)
22.	AR21839	[2]	Clamp
23.	T24760	[1]	Hose	(TO CLUTCH HOUSING OIL LINE)
24.	T22900	[1]	Deflector
25.	R35339	[1]	Isolator
...	T11847	[1]	Sealant	(NO LONGER AVAILABLE)
...	RE12842	[1]	Coolant	.91 KG (32 OZ.) (SUB FOR T19566)
