约翰迪尔零件查询401C - BACKHOE, LOADER THERMOSTAT HOUSING ASSEMBLY [01C18]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
780 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3385
|
[2] |
Cap Screw
|
|
| 2. |
12H304
|
[2] |
Lock Washer
|
|
| 3A. |
T23620
|
[1] |
Cover
|
|
| 3B. |
T20317
|
[1] |
Cover
|
|
| 4. |
T20215
|
[1] |
Gasket
|
|
| 5. |
AT24013
|
[1] |
Thermostat
|
|
| 5. |
RE33705
|
[1] |
Thermostat
|
|
| 6. |
T19651
|
[1] |
Hose Fitting
|
|
| 7. |
15H561
|
[1] |
Pipe Plug
|
|
| 8A. |
T20277
|
[1] |
Hose
|
|
| 8B. |
T12815
|
[1] |
Hose
|
|
| 9. |
AR21837
|
[2] |
Clamp
|
|
| 10. |
T20219
|
[1] |
Gasket
|
|
| 11. |
19H1726
|
[2] |
Cap Screw
|
|
| 12. |
19H2855
|
[2] |
Cap Screw
|
|
| 13. |
T28748
|
[1] |
Housing
|
|
| 14. |
T19651
|
[1] |
Hose Fitting
|
|
| 15. |
T20212
|
[1] |
Gasket
|
|
| 16. |
T30532
|
[1] |
Hose
|
|
| 17. |
T20317
|
[1] |
Cover
|
|
| 18. |
AR73097
|
[1] |
Housing
|
|
