约翰迪尔零件查询401C - BACKHOE, LOADER ENGINE CLUTCH AND FLYWHEEL (NO PTO) (WITHOUT REVERSER) [01E15]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询401C - BACKHOE, LOADER ENGINE CLUTCH AND FLYWHEEL (NO PTO) (WITHOUT REVERSER) [01E15]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 356 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20088	[1]	Gear	(142 TEETH)
2.	AT18045	[1]	Flywheel
3.	19H2993	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/2" (SUB FOR R46162, THIS APPLICATION)
4.	AR63695	[1]	Clutch Disk
5.	AT35213	[1]	Clutch Plate	(SUB AT25817, THIS APPLICATION)
6.	AR43065	[1]	Thrust Bearing
7.	R51469	[1]	Planet Pinion Carrier
8.	T21450	[1]	Extension Spring
9.	T21999	[1]	Fork
10.	AT19837	[1]	Shaft
11.	34H353	[2]	Spring Pin	3/8" X 1-3/4"
12.	T21446	[1]	Bushing
13.	L372T	[6]	Cap Screw
14.	12H303	[6]	Lock Washer	5/16"
15.	T15940	[3]	Washer	(USE IF AVAILABLE)
15.	24H1657	[1]	Washer	21/64" X 1-1/4" X 7/64", (SUB FOR T15940)
16.	........	[1]	Plate	( T39871 NO LONGER AVAILABLE)
17.	........	[1]	Bracket	( T35299 NO LONGER AVAILABLE)
18.	........	[6]	Spring	( T35295 NO LONGER AVAILABLE)
19.	........	[3]	Lever	( T35301 NO LONGER AVAILABLE)
20.	........	[3]	Link	( T35298 NO LONGER AVAILABLE)
21.	........	[1]	Ring	( T35300 NO LONGER AVAILABLE)
22.	T35296	[3]	Clamp
23.	T35294	[3]	Bolt
24.	........	[3]	Pin	( T35297 NO LONGER AVAILABLE)
25.	14H882	[3]	Nut	5/16", (SUB FOR T39870)
