约翰迪尔零件查询401C - BACKHOE, LOADER ENGINE AND PTO CLUTCH AND FLYWHEEL (CONTINUOUS PTO WITHOUT REVERSER) [01E16]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 461 次

Pos.	Part No	Qty	Parts name	Comments
1.	T20088	[1]	Gear	(142 TEETH)
2.	AR66779	[1]	Flywheel
3.	19H2898	[4]	Cap Screw	HS, SAE 8, 1/2" X 1-1/4"
4.	RE29881	[1]	Clutch Disk	(SUB FOR AT32207 AND AR66923)
5.	T23008	[3]	Bolt
6.	T22194	[1]	Clutch Plate
7.	R26638	[9]	Spring	INNER
8.	T22927	[9]	Spring	OUTER
9.	R27033	[9]	Round Retainer
10.	T22195	[1]	Clutch Plate
11.	AL19092	[1]	Clutch	(DIESEL) (SUB FOR AT21675)
11.	RE31382	[1]	Clutch Disk	(GASOLINE) (SUB FOR AT20916)
12.	T27706	[1]	Cover
13.	19H3385	[6]	Cap Screw	1/2" X 1-1/8"
14.	14H774	[6]	Nut	3/8"
15.	T27708	[3]	Pin Fastener
16.	AR43065	[1]	Thrust Bearing
17.	T21450	[1]	Extension Spring
18.	T24381	[3]	Dowel Pin
19.	R51469	[1]	Planet Pinion Carrier
20.	T21999	[1]	Fork
21.	T21446	[1]	Bushing
22.	AT19837	[1]	Shaft
23.	34H353	[2]	Spring Pin	3/8" X 1-3/4"
24.	T27707	[3]	Spring
25.	24H1322	[6]	Washer	29/64" X 13/16" X 0.065"
26.	11M7059	[3]	Cotter Pin	3.200 X 20 MM
27.	T21932	[3]	Bar
28.	R96514	[3]	Lever	(SUB FOR T22197)
