| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | L35845 | [1] | Hose | OIL COOLER TO CLUTCH HOUSING OIL LINE (WITH REVERSER) (SUB FOR T24760, THIS APPLICATION) |
| 1. | ........ | [1] | Hose | (WITHOUT REVERSER) (.69 AND 1.38 PUMP) 114 MM LONG (3/4" X 4-1/2") (MAKE FROM R57300 BULK MATERIAL, CUT TO LENGTH) (SUB FOR R34603) |
| 1. | ........ | [1] | Hose | 1/4 MM LONG (3/4" X 4-1/2") (WITHOUT REVERSER) (3.01 PUMP) (MAKE FROM T61939, 3 M (10 FT.) BULK) (SUB FOR T35692 AND T21371) |
| 2. | AR21839 | [1] | Clamp | |
| 3. | AT22143 | [1] | Oil Line | OIL COOLER TO CLUTCH HOUSING OIL LINE (WITHOUT REVERSER) |
| 3. | AT22263 | [1] | Oil Line | OIL COOLER TO CLUTCH HOUSING OIL LINE (WITH REVERSER) |
| 4. | R1662R | [1] | Washer | |
| 5. | R44302 | [1] | Tie Band | (WITH MANUAL STEERING) |
| 6. | T23083 | [1] | Tube | |
| 7. | T19324 | [2] | Clamp | |
| 8. | R44302 | [1] | Tie Band |
