约翰迪尔零件查询401C - BACKHOE, LOADER LOADER FOUR-WAY REGENERATIVE VALVE (SERIAL NO. -259661) [02D01]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
448 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT29940
|
[1] |
Cap
|
|
| 2. |
U41299
|
[1] |
Screw
|
|
| 3. |
H26238
|
[1] |
Guide
|
|
| 4. |
U11336
|
[1] |
Spring
|
|
| 5. |
H26237
|
[1] |
Washer
|
|
| 6. |
H26239
|
[1] |
Washer
|
|
| 7. |
........
|
[1] |
|
|
| 8. |
U11343
|
[2] |
O-Ring
|
|
| 9. |
........
|
[1] |
Spool
|
|
| 10. |
32240
|
[1] |
O-Ring
|
|
| 11. |
U40727
|
[2] |
Back-Up Ring
|
|
| 12. |
P47908
|
[2] |
O-Ring
|
|
| 13. |
U40729
|
[1] |
Back-Up Ring
|
|
| 14. |
U16016
|
[1] |
Poppet
|
|
| 15. |
U16015
|
[1] |
Spring
|
|
| 16. |
AU13748
|
[1] |
Check Valve
|
|
| 17. |
U40728
|
[1] |
Back-Up Ring
|
|
| 18. |
R27928
|
[1] |
O-Ring
|
|
| 19. |
........
|
[1] |
Housing
|
|
| 20. |
34H262
|
[1] |
Spring Pin
|
|
| 21. |
U41516
|
[1] |
Ring
|
|
| 22. |
R34802
|
[1] |
O-Ring
|
|
| 23. |
AU40992
|
[1] |
Plug
|
|
| ... |
AU40988
|
[1] |
Spool Valve
|
|
| ... |
AU40902
|
[1] |
Kit
|
|
