Pos.	Part No	Qty	Parts name	Comments
1.	U14394	[2]	Cap Screw	3/8" X 5-1/4"
2.	14H807	[1]	Nut	7/16"
3.	12H293	[1]	Lock Washer	7/16"
4.	U13946	[2]	Washer
5.	U15192	[3]	O-Ring	(A) 1/16" X 7/8"
6.	U15415	[3]	O-Ring	(A) 1/16" X 1-3/8"
7.	U11326	[6]	O-Ring	(A) 1/16" X 1-1/8"
8.	P51212	[6]	O-Ring	(A) 1/16" X 7/16"
9.	P47908	[1]	O-Ring	3/32" X 15/16"
10.	U40727	[1]	Back-Up Ring	1/16" X 15/16"
11.	32240	[1]	O-Ring	3/32" X 7/8"
12.	U11427	[1]	Plug
13.	U15564	[1]	Bolt	20 UNF, 7/16" X 7"
14.	U15537	[1]	Port Plate
15.	AU40988	[1]	Spool Valve	FOUR-WAY GENERATIVE
16.	AU40848	[1]	Spool Valve	FOUR-WAY FLOAT
17.	32240	[4]	O-Ring	3/32" X 7/8"
18.	AU40752	[1]	Pressure Relief Valve	190 BAR (2750 PSI)
19.	U11427	[1]	Plug
20.	AU40528	[1]	Pressure Relief Valve	103 BAR (1500 PSI)
21.	U11498	[1]	Ball
22.	34H264	[1]	Spring Pin	5/32" X 7/8"
23.	AU10997	[1]	Check Valve
24.	U15540	[1]	End Plate
...	AU40987	[1]	Control Valve	(SUB AT29662 AND AT53446)
...	AU40927	[1]	Seal Kit	REPAIR (FOR BETWEEN SECTIONS)
