| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U12547 | [4] | O-Ring | |
| 2. | AU11654 | [3] | Fitting | |
| 3. | AW10642 | [1] | Hydraulic Hose | 1 448 MM LONG (3/4" X 57") |
| 4. | 19H3065 | [1] | Cap Screw | 3/8" X 2" |
| 4. | 12H304 | [1] | Lock Washer | 3/8" |
| 4. | 14H812 | [1] | Nut | 3/8" |
| 5. | ........ | [1] | Clamp | ( U41132 USE IF AVAILABLE) |
| 6. | 28H1496 | [1] | Spacer | 3/8" X 1-1/8" |
| 7. | U13243 | [1] | Elbow Fitting | |
| 8. | AP23222 | [1] | Elbow Fitting | |
| 9. | AW12152 | [1] | Hydraulic Hose | 1 626 MM LONG (3/4" X 64") |
| 10. | AU11654 | [1] | Fitting |
