约翰迪尔零件查询401C - BACKHOE, LOADER COUNTERWEIGHT BRACKET [02D17]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
688 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
08H4283
|
[2] |
Cap Screw
|
|
| 2. |
24H1138
|
[4] |
Washer
|
|
| 3. |
19H1708
|
[2] |
Cap Screw
|
|
| 4. |
12H294
|
[2] |
Lock Washer
|
|
| 5. |
24H1698
|
[2] |
Washer
|
|
| 6. |
........
|
[1] |
Cradle
|
|
| 7. |
14H794
|
[2] |
Nut
|
|
| 8. |
U10104
|
[4] |
Bushing
|
|
| 9. |
14H1048
|
[2] |
Nut
|
|
| 10. |
12H234
|
[2] |
Lock Washer
|
|
| 11. |
U40588
|
[2] |
Bushing
|
|
| 12. |
12H236
|
[2] |
Lock Washer
|
|
| 13. |
19H2725
|
[2] |
Cap Screw
|
|
| 14. |
........
|
[1] |
Bracket
|
|
| 15. |
8255CU
|
[1] |
Weight
|
|
