约翰迪尔零件查询401C - BACKHOE, LOADER BACKHOE MAST AND SWING LINKAGE (9250 BACKHOE) [02D23]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 437 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2710	[4]	Cap Screw	HS, SAE 8, 5/8" X 1-3/4"
2.	U43183	[6]	Washer
3.	U43182	[4]	Tapered Sleeve
4.	U43210	[1]	Pin Fastener	SWING CYLINDER TO MAIN FRAME
5.	AU42103	[1]	Quick Lock Pin
6.	U43220	[1]	Bushing
7.	19H2717	[4]	Cap Screw	HS, SAE 8, 3/4" X 1-3/4"
8.	U43180	[6]	Spacer
9.	U43179	[6]	Tapered Sleeve
10.	U43184	[1]	Pin	INNER SWING LINKS TO MAIN FRAME
11.	U43203	[2]	Bushing	INNER AND OUTER SWING LINK
12.	U43163	[2]	Bushing	INNER
13.	U43202	[2]	Bushing	INNER
14.	AU42100	[1]	Link	INNER, UPPER, (INCLUDES R43163, U43202, U43203 AND JD7797)
15.	U43213	[1]	Spacer
16.	AU42101	[1]	Link	INNER, LOWER, (INCLUDES U43163, U43202, U43203 AND JD7797)
17.	JD7797	[7]	Lubrication Fitting	1/4", STRAIGHT
18.	U43177	[1]	Tapered Sleeve
19.	U43209	[1]	Pin Fastener	INNER LINKS TO OUTER LINK
20.	U43211	[1]	Tapered Sleeve	LOWER
21.	U43207	[1]	Pin	OUTER SWING LINK
22.	AU42102	[1]	Link	OUTER, (INCLUDES U43207, U43203 AND JD7806)
23.	U43212	[2]	Bolt
24.	U43208	[2]	Pin	SWING FRAME TO MAIN FRAME
25.	U40304	[1]	Bushing	UPPER
26.	11M7030	[1]	Cotter Pin	5 X 40 MM
27.	U43218	[1]	Pin
28.	28316	[1]	Spring Locking Pin	(SUB FOR S2955DW, THIS APPLICATION)
29.	U40305	[1]	Bushing
30.	AU42099	[1]	Frame	(INCLUDES U40304 AND U40305)
31.	19H2994	[2]	Cap Screw	HS, SAE 8, 5/8" X 1-1/2"
32.	U43219	[1]	Pin	BOOM CYLINDER TO SWING FRAME
33.	19H2472	[2]	Cap Screw	HS, SAE 8, 1/2" X 1"
34.	U43645	[2]	Washer
35.	JD7806	[2]	Lubrication Fitting	1/4"
