约翰迪尔零件查询401C - BACKHOE, LOADER BACKHOE VALVE BOX (9250 BACKHOE) [02D24]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
955 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3239
|
[6] |
Cap Screw
|
|
| 2. |
12H304
|
[4] |
Lock Washer
|
|
| 3. |
24H1305
|
[6] |
Washer
|
|
| 4. |
R20759
|
[2] |
Grommet
|
|
| 5. |
AT42429
|
[1] |
Box
|
|
| 6. |
12H304
|
[2] |
Lock Washer
|
|
| 7. |
14H812
|
[2] |
Nut
|
|
| 8. |
U41123
|
[1] |
Strap
|
|
| 9. |
19H1895
|
[3] |
Cap Screw
|
|
| 10. |
24H1625
|
[1] |
Washer
|
|
| 11. |
U41121
|
[1] |
Valve Cover
|
|
| 12. |
24H1287
|
[8] |
Washer
|
|
| 13. |
12H302
|
[8] |
Lock Washer
|
|
| 14. |
19H1227
|
[8] |
Cap Screw
|
|
| 15. |
U40357
|
[1] |
Valve Cover
|
|
| 16. |
12H301
|
[2] |
Lock Washer
|
|
