现代零件查询25/30LC-7A 3-SPOOL CONTROL LEVER(STD)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
691 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
37HC-40130
|
[1] |
MCV LEVER SUB ASSY
|
|
| N . |
37HC-40130
|
[1] |
MCV LEVER SUB ASSY
|
|
| 3. |
31HA-40220
|
[1] |
LEVER ASSY-CONTROL
|
|
| 3-1. |
31HA-40171
|
[1] |
LEVER WA-CONTROL
|
|
| 3-2. |
31HG-40101
|
[1] |
BOOT-LEVER
|
|
| 3-3. |
31HA-40570
|
[1] |
KNOB-NO SYMBOL
|
|
| 3-4. |
S205-101006
|
[1] |
NUT-HEX
|
|
| 3-5. |
31HA-40060
|
[1] |
LINK(42MM)
|
|
| 3-6. |
FAC1000640-01
|
[1] |
PIN-LEVER
|
|
| 3-7. |
S501-050002
|
[1] |
PIN-SELF LOCKING
|
|
| 4. |
31HA-40230
|
[1] |
LEVER ASSY-CONTROL
|
|
| 4-1. |
31HA-40181
|
[1] |
LEVER WA-CONTROL
|
|
| 4-2. |
31HG-40101
|
[1] |
BOOT-LEVER
|
|
| 4-3. |
31HA-40570
|
[1] |
KNOB-NO SYMBOL
|
|
| 4-4. |
S205-101006
|
[1] |
NUT-HEX
|
|
| 4-5. |
31HA-40060
|
[1] |
LINK(42MM)
|
|
| 4-6. |
FAC1000640-01
|
[1] |
PIN-LEVER
|
|
| 4-7. |
S501-050002
|
[1] |
PIN-SELF LOCKING
|
|
| 5. |
31HA-40240
|
[1] |
LEVER ASSY-CONTROL
|
|
| 5-1. |
31HA-40191
|
[1] |
LEVER WA-CONTROL
|
|
| 5-2. |
31HG-40101
|
[1] |
BOOT-LEVER
|
|
| 5-3. |
31HA-40570
|
[1] |
KNOB-NO SYMBOL
|
|
| 5-4. |
S205-101006
|
[1] |
NUT-HEX
|
|
| 5-5. |
31HA-40060
|
[1] |
LINK(42MM)
|
|
| 5-6. |
FAC1000640-01
|
[1] |
PIN-LEVER
|
|
| 5-7. |
S501-050002
|
[1] |
PIN-SELF LOCKING
|
|
| 6. |
31HA-40054
|
[1] |
BRACKET-MCV WA
|
|
| 8. |
31HA-40073
|
[1] |
PAD-SPONGE
|
|
| 9. |
31HG-40081
|
[1] |
COVER-MCV
|
|
| 10. |
31EK-11130
|
[1] |
COUPLING-SCREW
|
|
| 11. |
31HA-40111
|
[1] |
SHAFT-M.C.V LEVER
|
|
| 12. |
FAC1000640-01
|
[3] |
PIN-LEVER
|
|
| 13. |
S501-050002
|
[3] |
PIN-SELF LOCKING
|
|
| 14. |
31HA-40700
|
[1] |
CAP-SYMBOL,LIFT
|
|
| 15. |
31HA-40710
|
[1] |
CAP-SYMBOL,TILT
|
|
| 16. |
31HA-40720
|
[1] |
CAP-SYMBOL,NONE
|
|
| 17. |
31HA-40730
|
[1] |
CAP-SYMBOL,SIDE SHIFT
|
|
| 17. |
31HA-40740
|
[1] |
CAP-SYMBOL,F/POSI
|
|
| 17. |
31HA-40750
|
[1] |
CAP-SYMBOL,L/STABILIZER
|
|
| 17. |
31HA-40760
|
[1] |
CAP-SYMBOL,ROTATING
|
|
| 19. |
31HG-40111
|
[1] |
CAP-COVER
|
|
| 20. |
31FV-40230
|
[1] |
BOSS-SPACER
|
|
| 21. |
31HA-40150
|
[3] |
BOOT-SPOOL
|
|
| 22. |
S037-102016
|
[4] |
BOLT-W/WASHER
|
|
| 23. |
S037-102516
|
[2] |
BOLT-W/WASHER
|
|
| 24. |
S037-123036
|
[4] |
BOLT-W/WASHER
|
|
| 27. |
S631-011004
|
[1] |
O-RING
|
|
| 28. |
S275-120006
|
[1] |
NUT-SELF LOCKING
|
|
| 29. |
S741-121220
|
[1] |
DU BUSHINGH-FLANGE
|
|
| 30. |
31HG-40091
|
[1] |
COVER-MCV
|
|
| 32. |
S403-10500B
|
[1] |
WASHER-PLAIN
|
|
| 33. |
S109-100256
|
[1] |
BOLT-SOCKET
|
|
| 34. |
S411-100006
|
[1] |
WASHER-SPRING
|
|
| 35. |
31HA-40200
|
[3] |
BOOT
|
|
