现代零件查询25/30LC-7A HYDRAULIC OIL TANKEPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
389 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
30HC-35101
|
[1] |
HYD TANK GROUP
|
|
| N . |
30HC-35101
|
[1] |
HYD TANK GROUP
|
|
| 1. |
35HC-30030
|
[1] |
FLANGE ASSY-TANK
|
|
| 2. |
S632-125004
|
[1] |
O-RING
|
|
| 3. |
F42650010
|
[1] |
FILTER-RETURN
|
|
| 4. |
FHC1007100
|
[1] |
STRAINER-SUCTION
|
|
| 5. |
31HM-30010
|
[1] |
CAP-HYD OIL
|
|
| 6. |
31HM-30041
|
[1] |
HOSE-BREATHER
|
|
| 7. |
31FV-30031
|
[1] |
CAP-AIR BREATHER
|
|
| 8. |
F23650200
|
[1] |
FILTER-AIR BREATHER
|
|
| 9. |
31HM-30020
|
[1] |
PLUG-MAGNETIC
|
|
| 10. |
S631-014004
|
[5] |
O-RING
|
|
| 12. |
S035-082026
|
[6] |
BOLT-W/WASHER
|
|
| 13. |
31HA-30060
|
[1] |
DIPSTICK-HYD TANK
|
|
| 14. |
S035-061526
|
[1] |
BOLT-W/WASHER
|
|
| 15. |
31HA-20160
|
[1] |
CONNECTOR-BULK HOSE
|
|
| 16. |
31HA-20170
|
[2] |
CONNECTOR-BULK HOSE
|
|
| 21. |
31HM-30031
|
[1] |
CONNECTOR-BULK HOSE
|
|
| 22. |
33HA-83400
|
[2] |
HOSE CLIP
|
|
