约翰迪尔零件查询410 - BACKHOE, LOADER CRANKSHAFT AND IDLER GEARS [01B21]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 481 次

Pos.	Part No	Qty	Parts name	Comments
1.	R48685	[1]	Dowel Pin	(SUB FOR A120R)
2.	........	[1]	Crankshaft	RE33197,MARKED R121018 NO LONGER AVAILABLE (SUB FOR AT18030,MARKED T23519 OR T23480, AND RE57664,MARKED R81959)(DIESEL) SUB RE48748-CRANKSHAFT KIT.
2.	........	[1]	Crankshaft	(GASOLINE)(NO LONGER AVAILABLE) (MARKED T28743)
3.	26H72	[1]	Shaft Key	1/8" X 5/8"
4.	T26324	[2]	Thrust Washer
5.	R109863	[1]	Shaft	(SUB FOR T26323 AND R89824)
6.	34H283	[1]	Spring Pin	3/16" X 1-1/8"
7.	AR91660	[1]	Gear	UPPER IDLER, (MARKED R70182) (SUB FOR AT18009) (MARKED T20029) (55 TEETH)
8.	T20034	[1]	Bushing
9.	T26326	[2]	Thrust Washer
10.	T26327	[1]	Screw
11.	19H2993	[1]	Cap Screw	1/2" X 1-1/2"
12.	T20217	[1]	Washer
13.	R80808	[1]	Pulley	(SUB FOR R47412 AND R59312)
14.	AT21608	[1]	Seal	(SUB AR67942)
14.	AR67942	[1]	Seal	FRONT
15.	T20046	[1]	Oil Slinger
16.	T20094	[1]	Helical Gear	(24 TEETH)
17.	T23604	[1]	Shaft Key
18A.	T26325	[2]	Screw
18B.	19H3183	[1]	Cap Screw	HS, SAE 8, 1/2" X 2-1/8"
19.	AT24252	[1]	Gear	LOWER IDLER, (MARKED T26322) (45 TEETH)
20.	T26321	[1]	Bushing
21.	34H286	[1]	Spring Pin	3/16" X 1-1/2"
22A.	R76126	[2]	Washer	(SUB FOR R42364)
22B.	R100105	[1]	Washer
23.	T26323	[1]	Shaft
23.	R109863	[1]	Shaft	(SUB FOR R89824)
24.	14H865	[1]	Nut	1/2"
