Pos.	Part No	Qty	Parts name	Comments
1.	AT29213	[4]	Piston Ring	STANDARD (SET OF 3 RINGS) (SUB AR55759)
1.	AR55759	[4]	Piston Ring Kit	(A) (B) (C) (SET OF 3 RINGS)
2.	R51112	[8]	Snap Ring	(SUB FOR M67T)
2.	M41029	[8]	Snap Ring
3.	T26149	[4]	Piston Pin
3.	R125754	[4]	Piston Pin	(SUB FOR R51731)
4.	RE53265	[4]	Piston	(C) (SUB FOR R51451, T30015 AND AR78310) (BOHN CORPORATION) WHEN RE53265 REPLACES AR78310 ALL PISTONS MUST BE REPLACED.
4.	AR55984	[4]	Piston	(A) (SUB AR77762)
4.	AR77762	[4]	Piston	(B)
5.	T23471	[1]	Bushing
5.	R55647	[4]	Bushing
6.	T20009	[8]	Cap Screw	(SUB R74194)
6.	R74194	[8]	Screw	(USE WITH AR55978 AND AT18005)
6.	R80033	[8]	Cap Screw	(USE WITH RE16495, RE19733 AND RE21076)
7.	RE19733	[4]	Connecting Rod	(SUB FOR AT18005)
7.	RE21076	[4]	Connecting Rod	(SUB FOR AR55978 AND RE16495)
8.	AT21138	[4]	Bearing	(SET OF (2) T20011)
8.	........	[4]	Bearing	( AT21122 NO LONGER AVAILABLE) 0.05 MM (.002") UNDERSIZE (SET OF (2) T23566)
8.	AT21124	[4]	Bearing	0.25 MM (.010") UNDERSIZE (SET OF (2) T23568)
8.	AT21126	[4]	Bearing	0.51 MM (.020") UNDERSIZE (SET OF (2) T23570)
8.	AT21128	[4]	Bearing	0.76 MM (.030") UNDERSIZE (SET OF (2) T23572)
...	AR71592	[4]	Piston-Liner Kit	(CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS)
...	AR78041	[4]	Piston-Liner Kit	(CONTAINS CYLINDER LINER WITH O-RINGS AND PISTONS WITH PISTON RINGS)
...	AR71593	[4]	Piston-Liner Kit	(CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS) (SUB FOR AR82286)
