约翰迪尔零件查询410 - BACKHOE, LOADER PISTONS AND CONNECTING RODS (GASOLINE) [01C03]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询410 - BACKHOE, LOADER PISTONS AND CONNECTING RODS (GASOLINE) [01C03]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 483 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT18012	[4]	Piston Ring Kit	STANDARD, (SUB AR70633) (SET OF 3 RINGS)
1.	AR70633	[4]	Piston Ring Kit	(A) (SUB FOR AR55758) (SET OF 3 RINGS)
1.	AR55760	[4]	Piston Ring Kit	(B) (SET OF 3 RINGS)
2.	T18838	[4]	Piston Pin
3.	T24891	[4]	Piston	(A) STANDARD
3.	T24891	[4]	Piston	(SUB FOR T30179) HIGH ALTITUDE
3.	T23481	[4]	Piston	(SUB FOR T32017) HIGH ALTITUDE
3.	T30014	[4]	Piston	(B)
4.	M67T	[8]	Snap Ring	(SUB R51112)
4.	R51112	[8]	Snap Ring
5.	T526T	[4]	Bushing
6.	T15634	[2]	Nut
7.	T28745	[8]	Bolt
8.	AT26702	[4]	Connecting Rod
9.	AT10123	[4]	Bearing	STANDARD, (SET OF (2) T18925)
9.	AT21116	[4]	Bearing	0.05 MM (.002") UNDERSIZE (SET OF (2) T23560)
9.	AT21117	[4]	Bearing	0.25 MM (.010") UNDERSIZE (SET OF (2) T23561)
9.	AT21119	[4]	Bearing	0.51 MM (.020") UNDERSIZE (SET OF (2) T23563)
9.	AT10519	[4]	Bearing	0.76 MM (.030") UNDERSIZE (SET OF (2) T18939)
...	AR71595	[4]	Piston-Liner Kit	(CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTONS RINGS)
...	AR71594	[4]	Piston-Liner Kit	(CONTAINS CYLINDER LINER WITH O-RINGS AND PISTON WITH PISTON RINGS)
