Pos.	Part No	Qty	Parts name	Comments
1.	T38965	[1]	Muffler Extension	(WITHOUT CUSHION MOUNT PLATFORM) (SUB FOR T20844) (SUB FOR AT37781, THIS APPLICATION)
1.	........	[1]	Extension	(WITH CUSHION MOUNT PLATFORM) (SUB AT37780, THIS APPLICATION) (SUB FOR T35425)
2.	AT118733	[1]	Muffler	(DIESEL) (WITHOUT INSULATION) (SUB FOR AT32699)
2.	AT32700	[1]	Muffler	(GASOLINE) (WITH INSULATION)
2.	AT32701	[1]	Spark Arresting Muffler	(SPARK ARRESTING)
3.	14H812	[1]	Nut	3/8"
4.	28H1524	[1]	Spacer	3/8" X 7/8"
5.	12H304	[1]	Lock Washer	3/8"
6.	19H1726	[1]	Cap Screw	3/8" X 2-1/4"
7.	14H785	[2]	Nut	5/16", (USE WITH T19978)
8.	AT63813	[2]	Half Clamp	(SUB FOR T19978)
9.	12H303	[2]	Lock Washer	5/16"
10.	19H3552	[2]	Cap Screw	5/16" X 1-1/2"
11.	R98844	[1]	Gasket	(SUB FOR T20141)
12.	14H812	[1]	Nut	(A) (B) 3/8"
13.	19H2633	[1]	Cap Screw	(A) (B) 3/8" X 1-1/2"
14.	AR45917	[1]	Clamp	(A) (B)
15.	T38965	[1]	Muffler Extension	(A) (WITH CANOPY)
15.	T38966	[1]	Muffler Extension	(B) (WITHOUT CANOPY)
16.	AR45918	[1]	Clamp	(A) (B)
17.	........	[1]	Cap Screw	(A) (B) ( AR47785, NO LONGER AVAILABLE)
18.	AR56783	[1]	Exhaust Cap	(A) (B) (SUB AR86596)
18.	AR86596	[1]	Cap
...	AT37780	[1]	Extension	(WITH CANOPY) INCLUDES ALL PARTS IDENTIFIED BY (A)
...	AT37781	[1]	Extension	(WITHOUT CANOPY) INCLUDES ALL PARTS IDENTIFIED BY (B)
