| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | T20243 | [1] | Gasket | |
| 2. | R55405 | [1] | Gasket | |
| 3. | T30897 | [1] | Impeller | (SUB FOR T30897 OR R94419) |
| 4. | AR101549 | [1] | Seal Kit | |
| 5. | JD9257 | [1] | Ball Bearing | |
| 6. | T19653 | [1] | Elbow Fitting | |
| 7. | 15H584 | [1] | Pipe Plug | 1/2" |
| 8. | T23628 | [1] | Pulley | |
| 9. | 19H2127 | [4] | Cap Screw | 5/16" X 7/8" |
| 10. | R48993 | [2] | Tube | |
| 11. | M1098T | [2] | Cap | (USE AS REQUIRED) |
| 12. | RE21786 | [1] | Kit | (MARKED R55164) |
| 13. | RE25043 | [1] | Water Pump | (SUB FOR RE19717) |
