约翰迪尔零件查询410 - BACKHOE, LOADER ENGINE OIL COOLER (SERIAL NO. 169346- ) [01D05]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
915 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AR21837
|
[8] |
Clamp
|
|
| 2. |
T22942
|
[1] |
Hose
|
|
| 3. |
R48989
|
[1] |
Hose
|
|
| 4. |
R55126
|
[1] |
Line
|
|
| 5. |
R55128
|
[1] |
Flange
|
|
| 6. |
19H2855
|
[1] |
Cap Screw
|
|
| 7. |
R55127
|
[2] |
Hose
|
|
| 7. |
R99802
|
[2] |
Hose
|
|
| 8A. |
R70956
|
[1] |
Washer
|
|
| 8B. |
R105714
|
[1] |
Washer
|
|
| 9. |
R77332
|
[1] |
Pressure Relief Valve
|
|
| 10. |
R56947
|
[1] |
Drain Plug
|
|
| 11. |
T31306
|
[1] |
Threaded Nipple
|
|
| 12. |
21H1312
|
[1] |
Screw
|
|
| 13. |
12H295
|
[1] |
Lock Washer
|
|
| 14. |
R55129
|
[1] |
Half Clamp
|
|
| 15. |
24H1304
|
[1] |
Washer
|
|
| 16. |
R55125
|
[1] |
Line
|
|
| 17A. |
RE10869
|
[1] |
Oil Cooler
|
|
| 17B. |
RE31929
|
[1] |
Oil Cooler
|
|
