| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AR72957 | [1] | Coolant Heater | (SUB FOR AT27413) (PHILLIPS) |
| 2. | T29385 | [1] | Hose | 356 MM LONG (5/8" X 14") |
| 3. | AR21837 | [4] | Clamp | |
| 4. | T29388 | [2] | Union Fitting | |
| 5. | 15H613 | [2] | Elbow Fitting | 1/4" |
| 6. | T29384 | [1] | Hose | 406 MM LONG (5/8" X 16") |
| 7. | 24H1287 | [4] | Washer | 9/32" X 5/8" X 0.065" |
| 8. | 14H786 | [4] | Nut | 1/4" |
| 9. | R60123 | [1] | Bracket | (SUB FOR T29377) |
| 10. | 19H3267 | [2] | Cap Screw | 3/8" X 1-5/8" |
| 11. | 12H304 | [2] | Lock Washer | 3/8" |
| 12. | R28040 | [2] | Washer | |
| 13. | R60124 | [2] | U-Bolt | (SUB FOR T29380, THIS APPLICATION) |
| ... | AT27406 | [1] | Coolant Heater | (SUB AT72330, THIS APPLICATION) |
