Pos.	Part No	Qty	Parts name	Comments
1.	15-483	[2]	Screw	(SUB FOR B17696) NO. 6 X 1/4"
2.	T23524	[1]	Choke
3.	T12654	[1]	Venturi
4.	30-739	[1]	Float
5.	R10211	[1]	Shaft
6.	R10186	[1]	Seal
7.	R10187	[1]	Shim	.63 MM (.025")
8.	21H1315	[2]	Screw	0.164" X 3/4", (SUB FOR T23522, ALSO ORDER 12H379)
8.	12H379	[2]	Lock Washer	0.164"
9.	AT22990	[1]	Shaft
10.	T23523	[1]	Spring
11.	........	[1]	Lever	( AT22989 NO LONGER AVAILABLE)
12.	T23529	[1]	Snap Ring
13.	R10184	[1]	Swivel
14.	21H971	[1]	Screw	0.164" X 5/16"
15.	R10185	[1]	Spring Locking Pin
16.	15A295	[1]	Screw
17.	R10188	[1]	Clip
18.	AM117798	[1]	Kit	(SUB FOR AT22993 AND AM107391)
19.	T30519	[1]	Carbon Brush Holder
20.	34H242	[1]	Spring Pin	1/8" X 7/16"
21.	GW46-16-456	[1]	Gasket	( 16-456 NO LONGER AVAILABLE)
22.	T719T	[1]	Nozzle
23.	16-47	[1]	Gasket
24.	........	[1]	Needle	(USE WITH AT31877) ( AT22991 NO LONGER AVAILABLE) (SUB AR67706)
25.	T25152	[1]	Spring	(USE WITH AT31877)
26.	R34812	[1]	O-Ring	(SUB FOR T25154) (USE WITH AT31877)
27.	T25151	[1]	Screw	(USE WITH AT31877)
28.	T25156	[1]	Elec. Connector Terminal	(USE WITH AT31877)
29.	T25155	[1]	Electrical Connector Assy	(USE WITH AT31877)
30.	........	[1]	Clip	(USE WITH AT31877)
31A.	........	[1]	Solenoid	(SUB AR67706, THIS APPLICATION) (SUB FOR AT31877)
31B.	AR67706	[1]	Solenoid
32.	R10160	[1]	Pipe Plug
33.	99-4	[1]	Pipe Plug
34.	R10150	[1]	Plug
35.	AT30224	[1]	Housing
36.	T23532	[1]	Spring
37.	T23536	[1]	Bracket
...	AT29295	[1]	Carburetor	(ALSO ORDER AR67706 SOLENOID ASSEMBLY) (SUB RE39188)
...	AT30492	[1]	Kit	CARBURETOR REPAIR
