约翰迪尔零件查询410 - BACKHOE, LOADER CARBURETOR THROTTLE BODY ASSEMBLY (MARVEL-SCHEBLER NO. TSX-945SL) [01E15]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 1030 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2676	[2]	Cap Screw	HS, SAE 8, 3/8" X 1"
1.	12H304	[2]	Lock Washer	3/8"
2.	T10079	[1]	Gasket
3.	AT25821	[2]	Screw With Washer	(A)
4.	R56747	[1]	Accelerator	(A) (SUB FOR 14273, THIS APPLICATION)
5.	RE244066	[1]	Kit	(SUB FOR 16-654)
6.	........	[1]	Plug	(A) ( B17682 NO LONGER AVAILABLE)
7.	15A85	[4]	Screw	NO. 12 X 3/4"
8.	AT22998	[1]	Housing	(A)
9.	R10300	[1]	Plug	(A)
10.	JD8867	[2]	Needle Bearing	(A) (SUB FOR T23531)
11.	R10194	[1]	Packing	(A)
12.	R10182	[1]	Round Retainer	(A)
13.	T27410	[1]	Screw	(A)
14.	R10104	[1]	Spring	(A)
15.	AT25819	[1]	Shaft	(A)
16.	T25147	[1]	Pin Fastener	(A)
17.	T25158	[1]	Lever	(A)
18.	R31935	[1]	Snap Ring	(A)
19.	11M7075	[2]	Cotter Pin	1.200 X 12 MM, (SUB FOR T25150)
20.	T25149	[1]	Pin
21.	T23528	[1]	Strainer	(A)
22.	24-340	[1]	Spring
23.	43-33	[1]	Needle
24.	R10170	[1]	Gasket
25.	AT25491	[1]	Valve	(ALSO ORDER T23532, SPRING AND T23536 BRACKET)
26.	49-101L	[1]	Nozzle
27.	16A41	[1]	Gasket
...	AT29295	[1]	Carburetor	(ALSO ORDER AT31877 SOLENOID ASSEMBLY) (SUB RE39188)
...	AT30492	[1]	Kit	CARBURETOR REPAIR
