约翰迪尔零件查询410 - BACKHOE, LOADER CLUTCH HOUSING [01E20]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 956 次

Pos.	Part No	Qty	Parts name	Comments
1.	30H13	[AR]	Plug	1"
2.	T21827	[1]	Washer	(WITHOUT TACHOMETER)
3.	T22898	[1]	Plug	(WITHOUT TACHOMETER)
4.	R39112	[1]	Fitting
5.	R26375	[1]	O-Ring
6.	R26919	[1]	Washer
7.	19H2510	[2]	Cap Screw	HS, SAE 8, 1/2" X 1-5/8"
8.	T20168	[3]	Washer
9.	T12083	[1]	Plug	(A)
10.	T22851	[1]	Washer
10.	T68412	[1]	Washer	(USE WITH AT65216 CLUTCH HOUSING)
11.	34H251	[1]	Spring Pin	(A) 1/8" X 1"
12.	A4847R	[1]	Washer
13.	C2175R	[4]	Stud	(A)
13.	C2175R	[2]	Stud	(A)
14.	R30958	[4]	Lock Plate
15.	14H812	[4]	Nut	3/8"
16.	T22584	[1]	Bushing	(A) LUBRICATION TUBE
17.	T22585	[1]	Bushing	(A) PRESSURE
18.	T23212	[1]	Bushing	(A) PINION CARRIER SHAFT
19.	T36236	[1]	Gasket
20.	M4224T	[1]	Plug
21.	L1788C	[1]	Bushing	(A)
22.	R1680R	[2]	Plug	(SUB FOR T22569, THIS APPLICATION)
23.	R27567	[1]	Bushing	(A)
24.	R27320	[1]	Bushing	(A)
25.	AT33619	[1]	Housing	CLUTCH (MARKED T34503) (CONSISTS OF PARTS MARKED WITH AN (A)) (ALSO ORDER M1102T, L29854 AND 14H1039) (SUB AT65216) (ALSO ORDER (2) T68412)
25.	AT33619	[1]	Housing	(A) CLUTCH (MARKED T65860) (CONSISTS OF PARTS MARKED WITH AN (A)) (ALSO ORDER T26416, T21997, (4) R30958, (4) 14H1076, AT73276, (2) 12H304 AND (2) 19H1648) (SUB AT65216) (ALSO ORDER (2) T68412)
25.	AT65216	[1]	Housing	(A) CLUTCH (MARKED T67961) (CONSISTS OF PARTS MARKED WITH AN (A)) (ALSO ORDER T26416, T21997, (4) R30958, AT73276, (2) 12H304, (2) 19H1134, L29854 AND 14H1039)
26.	19H3170	[4]	Cap Screw	HS, SAE 8, 5/8" X 4-1/2"
27.	R70268	[4]	Washer	(SUB FOR (4) R42363)
28.	19M7084	[1]	Cap Screw	M8 X 15
29.	19H2735	[1]	Cap Screw	HS, SAE 8, 1/2" X 2"
30.	T23211	[1]	Bushing	(A)
31.	M1102T	[1]	Plug
32.	L29854	[1]	Rod
33.	14H1039	[1]	Nut	5/8"
